custom plastic POM sheet industry White POM-C POM-H board plate
Model Number :pom sheet, pom board
Material: POM, POM-ESD
Thickness: custom thickness
Size: custom size
Product name :Engineering plastic Acetal/Delrin/POM-ESD Anti-static sheet board
color: white, black, and other color
custom made: as per your drawing
certification: ISO9001
accessories :molded part custom made
sample :available
size customized: yes
formation method: mold pressing, casting
MOQ: 1 square meter
Packing: carton or wooden box
Product description:
POM-C otherwise known as Acetal Copolymer is an engineered plastic. The highly crystalline resins are strong, rigid and have a low coefficient of friction in comparison to metals and other plastics. It is also creep resistant and is recommend for applicat
POM-C otherwise known as Acetal Copolymer is an engineered plastic. The highly crystalline resins are strong, rigid and have a low coefficient of friction in comparison to metals and other plastics. It is also creep resistant and is recommend for applications where dimensional stability is important.
POM-H is a homopolymer acetal.This homopolymer acetal has exceptional sliding characteristics and good wear resistance properties. In comparison to POM-C, POM-H has a slightly higher density, hardness and strength due to its higher crystallinity. In addition, POM-H has good electrical insulating properties, as well as exceptional machining characteristics, making POM-H one of the most versatile engineering materials available today.
Property
Item No.
Unit
POM-C
POM-H
POM-H+PTFE
1
Density
g/cm3
1.41
1.43
1.50
2
Water absorption(23℃ in air)
%
0.2
0.2
0.17
3
Tensile strength
MPa
68
78
55
4
Tensile strain at break
%
35
35
10
5
Compressive stress(at 2%nominal strain)
MPa
35
40
37
6
Charpy impact strength (unnotched)
KJ/m2
≥150
≥200
≥30
7
Charpy impact strength (notched)
KJ/m2
7
10
3
8
Tensile modulus of elasticity
MPa
3100
3600
3200
9
Ball indentation hardness
N2
140
160
140
10
Rockwell hardness
-
M84
M88
M84
Product Display
Product features
Excellent mechanical properties, high mechanical strength, high hardness,good wear resistance. Low resistance, high coefficient of friction, easy to maintain,Good electrical properties, low power consumption, high dielectric strength and insulation resistance and arc resistance. Good wear resistance and fatigue, high hardness, especially solvent resistance, rigidity strength is particularly outstanding,There are good chemical stability, electrical insulation, dimensional stability, commonly used to replace copper, zinc, tin, lead and other non-ferrous metals
Customized Service
Certificate
Companies strictly enforce the ISO9001(2008)international quality certification system,the product quality conforms to the eu RoHS standard.
Our Factory
Our factory covers an area of 10,000 square meters Production equipment has the original American imported Haas CNC machining center, wire-electrode cutting, electrical discharge machine,Perforating machine, injection molding machine, CNC milling machine,CNC hobbing machine, CNC lathe, CNC milling machine, CNC lathe, CNC milling machine, grinding machine and other machinery and equipment.
A2. Regular plates in stock can be cut into small pieces as required
Q3. What are the colors of the boards?
A3. Nylon board: beige black, blue other colors can be customizedUHMWPE board: white, black, green, blue, yellow, other colors can be customized POM board: white, black Q4. What are your processing equipment?
