MC Nylon，means Monomer Casting Nylon, is a kind of engineering plastics used in comprehensive industries, has been applied almost every industrial field.The caprolactam monomer is first melted, and added catalyst, then poured it
blue mc nylon rod black nylon screw bushing nylon carbon fiber filled nylon rod cast nylon rod and sheet engineering plastics nylon rod
MC Nylon，means Monomer Casting Nylon, is a kind of engineering plastics used in comprehensive industries, has been applied almost every industrial field.The caprolactam monomer is first melted, and added catalyst, then poured it inside moulds at atmosphere pressure so as to shape in different castings,such as: rod, plate, tube. The molecule weight of MC Nylon can reach 70,000-100,000/mol, three times than PA6/PA66. Its mechanical properties are much higher than other nylon materials, such as: PA6/PA66.
Color：Natural、White、Black、Green、Blue、Yellow、Rice Yellow、Gray and so on. Sheet Size：1000X2000X(Thickness:1-300mm）、1220X2440X(Thickness:1-300mm) 、1000X1000X(Thickness:1-300mm）、1220X1220X(Thickness:1-300mm) Rod Size: Φ10-Φ800X1000mm Tube Size: (OD)50-1800 X (ID)30-1600 X Length(500-1000mm)
| / | Item No. | Unit | MC Nylon (Natural) | Oil Nylon+Carbon (Black) | Oil Nylon (Green) | MC901 (Blue) | MC Nylon+MSO2 (Light black) |
| 1 | Density | g/cm³ | 1.15 | 1.15 | 1.35 | 1.15 | 1.16 |
| 2 | Water absorption (23℃ in air) | ％ | 1.8-2.0 | 1.8-2.0 | 2 | 2.3 | 2.4 |
| 3 | Tensile strength | MPa | 89 | 75.3 | 70 | 81 | 78 |
| 4 | Tensile strain at break | ％ | 29 | 22.7 | 25 | 35 | 25 |
| 5 | Compressive stress(at 2%nominal strain) | MPa | 51 | 51 | 43 | 47 | 49 |
| 6 | Charpy impact strength (unnotched) | KJ/m² | No break | No break | ≥5 | No BK | No break |
| 7 | Charpy impact strength (notched) | KJ/m² | ≥5.7 ≥6.4 | 4 | 3.5 | 3.5 | 3.5 |
| 8 | Tensile modulus of elasticity | MPa | 3190 | 3130 | 3000 | 3200 | 3300 |
| 9 | Ball indentation hardness | N2 | 164 | 150 | 145 | 160 | 160 |
| 10 | Rockwell hardness | - | M88 | M87 | M82 | M85 | M84 |
